Type B1 900 + 119 sq ft

Spaces labelled on the drawing

• GARDEN
• TERRACE
• ROOM 1
• ROOM 2
• ROOM 3
• ROOM 4
• BATH 1
• BATH 2
• LIVING
• DINING
• KITCHEN
• YARD
• FOYER
• AC

Rooms are labelled “ROOM” on the drawing.

As drawn

• The drawing shows a terrace (TERRACE) at the end of the living room, with the garden (GARDEN) running on past Room 1.
• A door is drawn at one corner of the garden; the drawing does not say where it leads.
• On the drawing, Room 1 has its own bathroom (BATH 1); the fourth room is the smallest.

Visible differences from the Type B drawing

• Where the Type B drawing shows a balcony and air-conditioner ledge (BALCONY / AC) at the end of the living room, the B1 drawing shows a terrace and a garden.
• The only air-conditioner ledge is drawn by the yard (YARD), longer than on the Type B drawing.
• The depth changes from Type B’s 9800 to 11250 (both as printed).

For every other detail, the Type B1 drawing itself and the sale and purchase agreement prevail. Lay the two over each other

Provided with the home (as listed on the developer’s plans)

Kitchen cabinets (upper and lower)	1
Induction hob	1
Cooker hood	1
Water heater (each bathroom)	2
Air-conditioners (living room and Room 1)	2

Dimensions printed on the drawing

Overall width 10,800 mm · depth 11,250 mm.

The developer writes these three as “800 + 119 sq ft”, “900 + 119 sq ft” and “1,050 + 119 sq ft” and calls them Garden Units; the drawings add a terrace (TERRACE) and a garden (GARDEN) to the base layout.
