Type A1 800 + 119 sq ft

Spaces labelled on the drawing

• GARDEN
• TERRACE
• ROOM 1
• ROOM 2
• ROOM 3
• BATH 1
• BATH 2
• LIVING
• DINING
• KITCHEN
• FOYER
• AC

Rooms are labelled “ROOM” on the drawing.

As drawn

• The drawing shows a terrace (TERRACE) at the end of the living room and a garden (GARDEN) beyond it; Room 1’s window also opens to the garden.
• A door is drawn at one corner of the garden; the drawing does not say where it leads.
• On the drawing, Room 1 has its own bathroom (labelled BATH 2 here).

Visible differences from the Type A drawing

• Where the Type A drawing shows a balcony and air-conditioner ledge (BALCONY / AC) at the end of the living room, the A1 drawing shows a terrace and a garden.
• The air-conditioner ledge (AC) is drawn outside, by the front door.
• The two bathrooms swap numbers compared with the Type A drawing (the one by Room 1 is labelled BATH 2).
• The depth is printed “1200”; scaled from the overall width printed on the same drawing (8,890 mm), the overall depth reads about 11.8 m (a reading from the drawing).

For every other detail, the Type A1 drawing itself and the sale and purchase agreement prevail. Lay the two over each other

Provided with the home (as listed on the developer’s plans)

Kitchen cabinets (upper and lower)	1
Induction hob	1
Cooker hood	1
Water heater (each bathroom)	2
Air-conditioners (living room and Room 1)	2

Dimensions printed on the drawing

Overall width 8,890 mm · depth printed “1200” (scaled from the 8,890 mm overall width: about 11.8 m, a reading from the drawing).

The developer writes these three as “800 + 119 sq ft”, “900 + 119 sq ft” and “1,050 + 119 sq ft” and calls them Garden Units; the drawings add a terrace (TERRACE) and a garden (GARDEN) to the base layout.
